[haknslash]

Info taken from my original post on hidplanet's forum. It can be applied here since I can manage it as time goes on.

*DISCLAIMER*

We are not responsible for your mechanical ability, and therefore can not be held liable for any mis intrepretation in the information provided to you.

NOTICE!!! Any website using this material without the author AND site administrators consent will be considered plagairism. If you are interested in using any of the info here contact me personally.


-------------------------------------------------------------------------------------------------

I took it upon my self to cover the bases so to speak so that you get a general idea of what all is involved with HID.

Class is in session...shall we start? :lol: :thumbsup:

Bulbs
Ok, first off, lets start with the bulbs. The common mistake some people here is that all these high kelvin rated bulbs are the shizzle. Well, they couldn't be more wrong. The higher you go in kelvin, the less light and lumens you'll have. Pratically anything over 6k is really a waste if your at all concerned with your safety and brightness of lighting. So what is the best bulb out there then you ask? 4100-4300k. It has the most lumens out of all the HID bulbs produced. Thats why car manifacturers still use them today. Below is a graph showing you the variances of the light spectrum. As you can see, 4100k would be right where the "sweet spot" is on that chart. It produces near to the suns same kelvin thus giving you daylight-like output. Think of it like this, high kelvin bulbs would be like being out in the sun with sunglasses on vs a 4100k being in the sun w/o glasses on.

Also here is another good thing to know taken from the FAQ:
Yellow:
1500 k Candlelight
2700-2900 k Yellow painted fog halogen bulbs
-------------------------------
Yellowish white:
3200 k Sunrise/sunset
3200 k Premium H7 non painted halogen bulb
3400 k 1 hour from dusk/dawn
-------------------------------
White:
4100 k Philips/Osram OEM HID D2S
5500 k Bright sunny daylight around noon
----------------
Blueish white
5500-5600 k Electronic photo flash
6000 k Philips Ultinon HID D2S
6500-7500 k Overcast sky
-----------------
Blue:
9000-12000 k Blue sky
-----------------
Purple:
28000 Northern sky
12000-30000 k Ultra Violet light (black light)


So why is 4300k often referred to as the best bulb to get?

Good question! Here's the answer, and proof....

4100-4300k best emits the most useable light in terms of lumen.

As you can see below, the 4100k-4300k bulb is going to have far more lumen (lm) than 6000k and up bulb. Notice this perticular 4200k bulb puts out a awesome 3400lm as its a 85122+. These generally put out 200 more lumen over the traditional 85122...

This is a data sheet for the Philips Ultionon 6000k bulb. It actually puts out 5800k color temp when new but as time progresses will be much more than that. As you can see, output performance dropped considerably for the worse. It only has performs now with 2400 lumen. Big loss in performance....

To show even more just how bad the performance and useable output deplinishes as you go up in kelvin, let me show you this data sheet for a GE 10000k bulb. HORRIBLE useable output performance of a measley 150 lumens. And that rating is with the bulb brand new, at its BEST performance peak LOL. As that thing begins to colorshift, hell I bet a tail light would put out more useable output than those

Some important terms to know:
Watt- Measure of electrical power (w)
Volt- Measure of electrical charge (v)
Kelvin- Measure of color temperature (K)
Lumen- Measure of light brightness (lu)
Capsule- tecnically correct term for a HID "bulb".
Candela- Measure of light intensity (cd)
Ampere- Measure of electrical current
Cut-off- A distinctive line of light produced by the shield in a headlight that blocks light above a certain height in order to prevent blinding of other motorists.
Beam Pattern- The pattern of light that is projected onto the ground which includes angle of lateral dispersion, width and depth of illumination.
Capsule- Another term for an HID bulb. Some refer to HID bulbs as gas discharge capsules.
Optics- The lighting control assembly structured around the bulb, which effects the dispersion of light and it's characteristics to a great degree.
HID (High Intensity Discharge)= Gas Discharge
Halogen= Incandescence



So now that you know about kelvin and some aspects of the bulbs, you might be wondering why you hear the terms D2R or D2S. Well, to put it very simply to you, D2R is a HID bulb that was designed for HID reflector housings. It has a different base than a D2S and also has a painted portion on the bulb itself. Why is it painted you ask? The paint is there to block certain areas of the bulb that would cause excessive glare in the housing. Does the paint affect bulb performance? Yes. A 4100k D2R has slightly less lumen than a 4100k D2S. Can a D2R be converted to a D2S? Yes. You would have to make a notch in the base of the bulb to match that of a D2S. you would also need to delicatly remove the painted portion of the bulb so that it would be completely visible just like a D2S. So enough about a D2R ehh, lets talk about the D2S for a sec. The D2S was designed soley for a HID projector applications. They are completely clear and give out the most efficiency of the two. Thats pratically all there is in difference between those two bulbs Below are some pics of both.

D2R

D2S

Lets move on shall we...

Ballasts
Ok, it has come to my attention some people think that if you use 2 different ballasts on the same bulbs, that one will look different than the other. Is this true? No. A ballast is a ballast (performance wise) as long as we are talking about 35W ballasts. As long as each ballast has the same exact style of connectors, they both can be used in conjunction with each other.

However, most aftermarket HID kit suppliers usually end up making their own sort of connector thus no longer using the oem style D-type connector. Thus that means some HID kits out there that use these different types of connectors, will no longer be able to connecto to a standard D2R or D2S based bulb. They make these kits like that to be universal with their rebased bulbs. If you ever plan on retroing projectors and using oem products, you aftermakret kit balast WILL NOT work and you will either have to replace the ballasts with oem components or be brave and splice in a new plug and oem connector.

So now you may be asking yourself, "so what all does a ballast do in general"? Well, here is a little bit of info on how flouresent ballast work and their basic simplicity. The same somewhat applies to automotive ballast. Our automotive ballast take in your cars DC power and converts it to AC current.

The simplest sort of ballast, generally referred to as a magnetic ballast, works something like an inductor. A basic inductor consists of a coil of wire in a circuit, which may be wound around a piece of metal. If you've read How Electromagnets Work, you know that when you send electrical current through a wire, it generates a magnetic field. Positioning the wire in concentric loops amplifies this field.

This sort of field affects not only objects around the loop, but also the loop itself. Increasing the current in the loop increases the magnetic field, which applies a voltage opposite the flow of current in the wire. In short, a coiled length of wire in a circuit (an inductor) opposes change in the current flowing through it (see How Inductors Work for details). The transformer elements in a magnetic ballast use this principle to regulate the current in a fluorescent lamp.

A ballast can only slow down changes in current -- it can't stop them. But the alternating current powering a fluorescent light is constantly reversing itself, so the ballast only has to inhibit increasing current in a particular direction for a short amount of time. Check out this site for more information on this process.

Magnetic ballasts modulate electrical current at a relatively low cycle rate, which can cause a noticeable flicker. Magnetic ballasts may also vibrate at a low frequency. This is the source of the audible humming sound people associate with fluorescent lamps.

Modern ballast designs use advanced electronics to more precisely regulate the current flowing through the electrical circuit. Since they use a higher cycle rate, you don't generally notice a flicker or humming noise coming from an electronic ballast. Different lamps require specialized ballasts designed to maintain the specific voltage and current levels needed for varying tube designs.

Ok, so now that you've read that, whats a electromagnet...

An Electromagnet
An electromagnet starts with a battery (or some other source of power) and a wire. What a battery produces is electrons.
If you look at a battery, say at a normal D-cell from a flashlight, you can see that there are two ends, one marked plus (+) and the other marked minus (-). Electrons collect at the negative end of the battery, and, if you let them, they will gladly flow to the positive end. The way you "let them" flow is with a wire. If you attach a wire directly between the positive and negative terminals of a D-cell, three things will happen:

Electrons will flow from the negative side of the battery to the positive side as fast as they can.

The battery will drain fairly quickly (in a matter of several minutes). For that reason, it is generally not a good idea to connect the two terminals of a battery to one another directly. Normally, you connect some kind of load in the middle of the wire so the electrons can do useful work. The load might be a motor, a light bulb, a radio or whatever.
A small magnetic field is generated in the wire. It is this small magnetic field that is the basis of an electromagnet.

With that being said, you now know the basics of what all is going on inside a ballast. The DC power from your car is being turned into AC power to supply the charge needed to power up the HID bulbs. The ballast throws out 23k +/-1-2k of volts to the HID bulbs upon start-up often refered to as warm-up. This is when you seeing HID trun on and start to change colors and get brighter as they warm. This usually lasts only around 25 seconds or so on OEM ballast. Cheaper aftermarket ballast tend to warm-up longer thus causing premature bulb life loss.

Sometimes when people first get HID, they tend to show boat infront of their friends turning their HID off/on rapidly. Is this good some say? The answer is no. If you've ever seen HID turned off and on you would of noticed a 4100k turns redish-orange for a second. This is the bulbs way of saying OUCH! What happens is the bulbs have already created Xenon gas to for the light but hasn't cooled back into salts and then when the bulbs are turned back on, the ballast are sending out a start-up of 23k volts which IS NOT a good thing. The bulbs already had enough Xenon in them to supply light and didn't need the 23k shot to them. This kills bulb lifespan.

So you've learned about ballasts and bulbs now. Lets move on to the wiring now shall we....

Some people out there just aren't aware of the dangers with wiring HID straight off of your existing oem wiring. Should a relay be used to power HID, yes and always needs to be used. Why you ask perhaps? Your oem halogen equiped car was never designed or intended from the manufacturer to use or run high voltage/high current/ high amperage HID ballasts. Ballast draw a imense amount of amps upon start-up and could very seriosuly damage your wiring and not just at where its connected. We are talking serious damage to fuse boxes, ecu's, or worse could short and cause fires on very old cares that even have a hard enough time trying to power halogen. The reason why is, that when the ballast "demand" power, your car has to supply it from somewhere. Lets say its tapped into your oem headlight wire ok. Now you power up the ballasts, the draw current from your wiring, your wiring might not be up to the task so its needs help, t searches for a source and before you know it, you've now weakend not only one source but two now just to try and supply the ballast good clean power. This is why a relay harness is needed. A relay harness gets its power straight from the battery via relays. These relays are then wired to go to your ballasts now.

To understand how a relay works, go here:http://www.mgcars.org.uk/electrical/body_relays.html<----Excellent link

More about relays! http://www.bcae1.com/relays.htm

-or this one-

http://electronics.howstuffworks.com/relay1.htm<-------link

What a relay does:
A relay is a kind of "remote controlled switch".

From the inception of the electric starter, some kind of remote switch was required in order to provide the power to the starter motor without bringing the heavy, unwieldy wires to the dash and, as a result, making them longer with consequent voltage drop. Having a remote switch allows application and interruption of current to be done at the most electrically efficient point in the circuit, even if it is the most ergonomically least suitable position. At first, starter motors were operated by pulling on a cable which operated the switch, much in the same way that a bonnet (hood) latch is still actuated today.

The solenoids used for inertial engaged starter motors were effectively relays. A switch, sometimes operated by a key, could pass a small current to the solenoid which would move an actuator that would in turn engage a bigger switch capable of carrying the very large current the starter required. Later, pre engaged starter motors required that the solenoid had to do more work, throwing the pinion into the ring gear before making the electrical connection to the motor itself, and so its electric current requirements went beyond the capability of the ignition/starter switch. To overcome this limitation, a relay was used to remotely switch the solenoid. Indeed, the first relay fitted to MGB's was for this very purpose.

Basically, inside a relay there is a small electromagnet that requires, in most automotive relays, about 0.25 Amps to operate it. Once this small current is flowing, the electromagnet can pull-in (or if so configured, let-go) a switch capable, depending on the relay, of controlling many times that current, but usually from 30 Amps to 70 Amps. Not only does the relay deliver more power to the load than could be efficiently achieved with a dash or column switch and its associated wiring but the dash switch and wires can be smaller, lower cost and have longer life owing to the minimal heating and arcing that results from switching, carrying and interrupting only 1/4 Amp.

A basic bottom view diagram of an ISO relay that you would use for our applications.

Now that you know how a relay works, lets look at some diagrams to show you which way you need to wire your car.

*These diagrams are property of the FAQ so I do not take credit for their design*

**Special thanks to Herman, Eric, Vick and everyone else for supplying such a great database for everyone to use at the FAQ.**

**************http://faqlight.carpassion.info/**************

NOTE-You'll need to use a diode for cars that use H4, 9004 or 9007 type bulbs in this type application so that power isn't turned off to the HID once high beams are in use.

Ok so now you know a good bit or you should be up to speed on things. But lets go over a few terminlogy we use for the projectors out there....

Ok, this is starting to get me irritated. Ok everyone is saying oh what is the e46 projector, is it the same as an m3 or what about the e55 is it the same as an e-class, Or what about the a6 is it the same as an rs6. And i know some are new comers and dont know much about the hid lingo or termonology, so this is why i am posting this. Ok let me set this straight:

Hella, stanley, bosch, valeo, Zkw, and kioto= They are all headlight and projector manufacturors.

E46= The current chassis code for the newer 99 to present 3-series models. Yes this does include the m3 because it is just a high performance 3 series coupe. In 99-01 they used low beam bosch projectors and in 2002-2004 they used bosch bi-xenon. But in the new 2005 models they use the new bi-xenon ZKW projector.


E55= the e55 is a high performance e-class mercedes benz sedan. This e-class family currently includes the e500 and e320, they all use the same projectors bi-xenon hella projectors. The mercedes "e55" projector is a different version of the hella bi-xenon than the audi's.


Rs6, a6= The rs6 is just a twin turbo v8 model of the audi a6 sedan and uses the exact same projectors as an audi a6. Now in the earlier years from 99-01 they used hella low beam projectors and in 2002-2004 they used hella bi-xenon projectors. In this forum the names for the newer bi-xenon projectors for the audis are the rs6 and a6 bi-xenon. The older low beams we call the a6 low beam because the audi rs6 was introduced in 2003? maybe 2002, and used the hella bi-xenon by then. The audi version is a different version of the hella bi-xenon, rather than say the e55.


7 series, e38 and e65, e60= The current Bmw 7 series sedans (e65) use the "e55 version" hella bi-xenon projectors. The older 7 series (e38) used the bosch low beam projectors. We just call them e38, e65, or 7 series bi-xenon depending on which car the projectors came from.


x5, e39, e60= The x5 is the Bmw sport utility vehicle that just happaned to use the same projectors as the 01-03 5 series sedan (e39). There is no such thing as an e39 bi-xenon projector because the e39's never came with bi-xenon. Now the older (e39s) 97-00 used the hella low beam projectors but were way different and werent seen in other cars. The 01-03 e39s got a facelift and different "angel eye" headlights with different projectors. The e39 bmw was made from 97-03. The e60 is the current 5 series updated sedan from 2004-present. They use the same version of hella bi-xenon projectors as the mercedes benz e-class "e55".


S2k, tl, tsx, fx and maxima= The honda s2000's came equipped with a powerful stanley/kioto made projector that hasnt been seen in any car so we called that projector the s2k. The tl came with a bi-xenon stanley made projector that hasnt been seen in any car so we called it the tl projector. The same with the Acura Tsx and the Infiniti fx45/fx35. But the Nissan Maxima uses a bi-xenon hella projector very similar to the "e55 hella bi-xenon" but has a different sheild. The a4.s4 uses a smaller version of the other valeo projectors. The saab uses a valeo bi-xenon and the cadillac and jaguars use the valeo projectors with a 3" lense.


Audi A4/S4, Valeo D1S/D2S, Valeo= Audi a4/s4 uses the Valeo xenon projectors. The Audi A4/s4 for the years 1999.5-2001 and S4 for the year 1999-2001 use a the D2S Valeo Projectors. In 2002 the Audi A4 switched to the new body style and changed the projectors from using a D2S type bulb to a D1S bulb, then later on the new s4 was added in 2004. The difference between the A4 and S4 is that the s4 is a performance version of the s4, much like the m3 of the 3-series. There are many versions of the valeo including the valeos with the large 3" lense and the valeo bi-xenon. The audi a4s that were eqipped with halogen got projectors that were an h7 version of the a4/s4 valeo d2s projectors.

You will probably be able to figure it out from here on. e39,e46,e38,s2k,tl,tsx,fx, these are all just names they have aquired because of the car they came euipped in. These are not the names that the manufacturors named them. It would be easier just to say "audi version of the hella bi-xenon" or "e38 version of the bosch low beam projector", Lol you know what i mean. Well I hoped this helped some people figure out our termonology on srtforums.
_________________




pictures courtesy of from members of HIDPlanet accord6 (special thanks to NEON_2NR for hosting!!)

http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_side-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_front-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_rear.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_front.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_side.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_quarter02.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_quarter01.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_side-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_front-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_side.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_rear.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_front.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_quarter03.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E60_quarter01.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_side-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_front-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_rear.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_front.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_side02.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_side01.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_quarter02.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/ZKW_quarter01.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_side-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_front-size.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_quarter01.jpg
http://img.photobucket.com/albums/v251/neon_2nr/hostedpics/E46single_quarter03.jpg





Ok, so now we've covered the basics and you feel confident somewhat to tackle your project. all you need now is a few ideas to help get you in the right direction. That being said, here are a few links (thanks to lilboi for the link research =D> ) to other peoples retros that might or might not help you out on your project...

http://www.emotors.ca/Articles/article.aspx?id=132

http://www.geocities.com/jvxdriver/a6_retrofit.htm

http://forums.vwvortex.com/zerothread?id=649072

http://faq.auto.light.tripod.com/car-tested-retro.htm

http://www.hidretro.com/page18.htm

http://josch.wilksfamily.com/HIDimages/HIDpage.htm

http://home.gwu.edu/~nloke/eclipsehidretro.html

http://spiicytuna.com/DSM/projector/

http://home.austin.rr.com/framefamily/HIDretrofit.html

http://stardust.as/crazy/gallery/album17

http://www.houseofthud.com/cartech/hids/index.html

http://www.hidforum.com/diy/

http://www.illusion-lighting.com/

http://hidforum.com/diy/e36bixenon.php

http://www.apexstunts.com/HID/

http://www.turntableteknicianz.com/carpics/S14%20HID.htm

http://www.vuehaongoy.com/headlamp.html

http://scummmy.no-ip.com/index.html

http://www.vuehaongoy.com/charlieddeccls2k.html

http://members.rogers.com/dodoman/DIY/HID%20Retrofit/index.htm

http://www.imagestation.com/album/pictures.html?show_all=1&id=4286864553&start=1

http://www.imagestation.com/album/pictures.html?show_all=1&start=1&id=4291002885

http://members.rogers.com/wewong_hid/index.html

http://home.houston.rr.com/quangdtran/hid.html

http://wagdaddy_1.tripod.com/HID.htm

http://mywebpages.comcast.net/syclone1/hid/page1.htm

What are some of the advancements in HID lighting technology?

Hella has provided the public with some great short videos to get you up to snuff with the current trends and technologies in HID lighting that is utilized on OEM HID equipped cars:

Halogen/Xenon

Bi-Xenon

Cornering Light

Bending Light

Adaptive Front/Lighting System

-Hak :thumbsup:



[SupeRfasT-4]

Great Info should help alot of people out, thanks



[raining_shadows]

wow...everything you wanted to know about bulbs...wow.



[CT_SRT]

all i can say is wow(scratches head)...wow.....haknslash is the man....



[E-BlueRocket]

there is SOOO much info right there, if anyone can think of questions to ask now.. they are a genious



[haknslash]

Glad you guys like the info. PLENTY more is to come. :thumbsup:



[Larrywoz]

OK..............previous posts have given alot of info.........more then I would ever want to know..lol

However..

All I really want to know is what bulb gives off the most lite and is compatatble with the SRT-4...



[E-BlueRocket]

its stated perfectly in the post, so you might wanna read it better

4100k has the most light output

and there isnt one specific bulb for our cars its mainly what kinda money you wanna put out



[morphiusrt]

but even though the other color hids are not as bright as 4300k aren't they still brighter than stock almost twice as much?



[haknslash]

but even though the other color hids are not as bright as 4300k aren't they still brighter than stock almost twice as much?

Color and brightness (intensity) are two different things. Imagine it like this, if you were in the woods with zero light around and all you had were two flashlights. A white beam one and a blue beam one. Which do you think is going to have the most useable light based soley off color and actually allow you to see go enough to walk thru woods? The white one would or even one that would be yellowish beam (halogen).



[morphiusrt]

but still my friend has the most blue hids i've ever seen and he can see better at night than i can with my stock lights, his are way brighter than my stocks with silverstars. i was just askin cuz this post makes it seem like buying color hids would be worst than stock halogens.



[bballin410s]

so buying 4300k would be the most BRIGHT lights, but 6000k would be more of the "blue" look that most ppl like and the next step above that say 8000k would be more purple?



[haknslash]

but still my friend has the most blue hids i've ever seen and he can see better at night than i can with my stock lights, his are way brighter than my stocks with silverstars. i was just askin cuz this post makes it seem like buying color hids would be worst than stock halogens.

Actually it would be worse than your stock lights. Several reasons why. For one yourgoing to have glare issues with using a plug and play HID "kit". For two your not going to have the correct beam pattern unlike how your stock set-up is due to you putting a HID capsule into a halogen designed reflector housing. HID emits light completely different than a filament type "bulb". Light is not dispsersed the same at all hence the reason why the housings on HID equipped vehicles are designed specifically for HID use therefore emiting the correct beam pattern without glare and with optimal performance. A HID kit, no matter what kevlin range in color, cannot and will not ever be able to compete on a level like that of OEM equipment.

Your friends headlights are brighter in intensity than your 55W halogen bulbs but only because the fact its HID. The problem or trick is that blue and your brain make you think things are brighter or would be easier to drive but that is far from the truth. Studies have shown that blue hues and your eye actually cause fatigue over long periods of driving behind the wheel. Blue is the color your eye really reacts to more so than any other color. If you think you can see better with blue versus white than your mistaken. Brighter isn't always better, in your case intensity isn't always better.



[morphiusrt]

thank you, for that explaination I looked as his last night and i could see what your saying.



[bballin410s]

haknslash what is your take on the best overall appearance/quality range for our cars without the projectors? 4300k or 6000k?



[CJohnson]

I had a plug-n-play kit. It was nice light output compared to stock. Im not gonna lie. The problem came when I was blinding every other driver. I just got to the point that the kit just wasnt worth me endangering other drivers. I would save for a retro. But if you are interested in HID's that will work for our cars, I have a kit that I will sell you that are the 8000ks. Bluish white tint to em. PM me if interested Kit comes complete with the Hella Ballasts.



[LuminaRS]

Wow, that's alot of really good info!

I somewhat have "cornering lights" on my car. It was an option that chevy decided not to go forward with. It would have been the oldschool cornering lights though that only came on with the blinkers. Mine have three different selections though. ON/OFF/ON with parking lights. They definately help on the back-ass dirt country roads around here!

That "Adaptive Front Lighting System", is that anything like the HID lights on the newer high class Mercedes Benz? I remember seeing this Benz a little back with the most trick headlights. The girl started the car, and the HID projector moved from pointing down, to pointing up, to pointing back down, to pointing up, to finally stopping slightly facing downwards. COOLIST thing I've ever seen before!! But unlike the adaptive lighting system, the whole entire projecting unit moved. Very very cool!

I'd love to do a retro in my car becuase my headlights are absolute crap. Only problem being that I have the 4 bulb setup in my car, and the lenses have built-in diffusers like most older-style cars. The only real probmel I think I would have are with the diffusers, because I could simply just use two kits and have 4 bulbs on constantly so I would in effect have 4 low beam and 4 hi beam. I've looked everywhere for info on doing a retro, and low and behold I've gotten more info from this forum than from anywhere else!



[Roach]

what parts are needed for retro exactly? would love to do but want to make as plug and play as possible wiring wise, thanks



[LVOBSRT]

im having a problem with my darksides hids, it seems like my drivier said on a second start up for the night will take all the power and not let me passanger side come on. the first start up of the night, they both come on but right side turns on a couple seconds later. swaped ballist and still on the right side it wont start up bulb works cuz like i said it comes on first time i use for the night. any one know what to do?



[haknslash]

^^^ you running a upgraded harness or no? Checked your MFS lately?
