First off Gregg and I would like to personaly thank steven (aka boostdacr) for driving 2 hours out of his way and letting us take our time on his car so we could get detailed pictures for installation.
tools needed:
1-10mm wrench
2-14mm wrenches
1-15/16 wrench
1-15/16 socket
1- ratchet
1 pair of channel locks
1-drill
1-1/2 inch drill bit
first remove the 2 bolts that hold the radiator in
![]()
yea these bolts
![]()
have a friend, spouse, neighbor....someone hold up on the radiator so you can get the 2 - 5/8 supplied bolts with washers through the the 2 outside slots on the radiator core support, put them in and then they can let the radiator go,make sure you put the washer on the bolt before puting it in the slot.
![]()
you will need to locate the 2 holes on the front crossmember and drill them out to 1/2"
![]()
we used a step drill to accomplish this
![]()
see the holes are now drilled out to 1/2"
![]()
have someone help you hold the H-brace up or use your belly like i did install the supplied 7/16" bolts from the H-brace to the front crossmember...... bolt order as follows from top to bottom (nylock nut, washer, front crossmember, H-brace, washer, bolt) just screw in hand tight for now.
![]()
next we just installed the 5/8" bolts into the core support hand tight (do not tighten yet) we used a c-clamp to draw it up to the core support.
![]()
next tighten the 7/16 bolts on the front crossmember
![]()
next install the traction bars bolt order as follows top to bottom (5/8 bolt, washer, core support, H-brace, washer, lock washer, heim joint, 5/8 nylock nut) and tighten up (don't forget to slide the heim joint through the safety break cable).
![]()
this is what it should look like
![]()
next we move on to the sway bar links, remove your stock ones there is not a nut on top you will have to use a pair of channel locks too hold the top while loosen it up from the bottom. next install the supplied energy suspension sway bar links bolt order as follows from top to bottom (nylock nut, retaining washer, bushing, control arm, bushing, retaining washer(up), retaining washer (down), bushing, sway bar, bushing, retaining washer (up), heim joint, delrin heim joint insert, supplied silver washer, bolt. tighten til the bushings expand out to the edge of the retianing washer.
![]()
check for clearance...i was able to get 2 of my fat fingers between the motor mount, the black plastic shield and the traction bar.
![]()
next adjust the traction bars....with the steering wheel straight and the weight of the car on the front tires (we adjusted on car ramps) tighten up on the traction bar tube by hand it should get shorter until it stops and it wont go any further, we then tightened it up a half a turn more with a rag to protect the knurl and a pair of channel locks, now tighten the jam nuts up.....take it for a spin with atleast 1 launch come back and tighten the sway bar links up a little more ( ours were loose after we got back ) if you still have wheel hop tighten the traction bar tube up a 1/4 turn at a time. Recheck all of your bolts to make sure everything is tight.
![]()
here is the finished product
![]()
